  1. Home
  2. Special Offers and Garage Storage Deals
  3. Auxx-Lift
$1,459
$2,150 Save $691



Auxx-Lift
Auxx-Lift
Auxx-Lift
Auxx-Lift
Auxx-Lift
Auxx-Lift
Auxx-Lift
Auxx-Lift
Auxx-Lift
Auxx-Lift
Auxx-Lift
Auxx-Lift
Auxx-Lift Auxx-Lift Auxx-Lift Auxx-Lift Auxx-Lift
Auxx-Lift Auxx-Lift Auxx-Lift Auxx-Lift Auxx-Lift Auxx-Lift Auxx-Lift
$1,459 Out of stock $2,150 Save $691
Product available
Product unavailable

Lower the garage storage platform lift at the push of a button. EASY Installation on joists and Rafters - Over 11,000 happy customers

  • No lifting or ladders
  • Steel aircraft cables (Lift tested to UL-standards)
  • Built in the USA - Uses SPAX® PowerLags®
  • Low ceiling hanging height - Competitor's lifts require 4+ ft.
    • INCLUDES: Motors with cables, Platform, Hardware, Remote, struts, step-by-step instructions - For the DIYer or handyman, but we also have installers in all states

Most Popular Out of Stock
3x6
Unavailable
 Most Popular Out of Stock
3x8
Unavailable
 Most Popular Out of Stock
4x6
Unavailable
 Most Popular Out of Stock
4x8
Unavailable

Most Popular Out of Stock
400LBS
Lifting Capacity
Unavailable
 Most Popular Out of Stock
600LBS
Lifting Capacity
Unavailable

Auxx-lift comes in two Powder-Coated Finishes
Most Popular Out of Stock
Silver Gray
Unavailable
 Most Popular Out of Stock
Pearl White
Unavailable
 Most Popular Out of Stock
Stainless Steel
Unavailable
Extra high ceiling?
Cable Extension Edit
Cable Extension
Cable Extension
Length:
Cable Extension
$100

Our hoist systems come standard with 12 feet of cable. Order this 18' cable for lifting in higher spaces.

Add Remove
Installation Services Edit
Installation Services
Installation Services
Option:
Installation Services
$0

We will connect you with a professional installer near you. You would pay the installer directly. 5-year warranty included

Add Remove
Additional hardware Kit Edit
Additional hardware Kit
Additional hardware Kit
Lift:
Additional hardware Kit
$99

The Auxx-Lift can be mounted on any ceiling (rafters/joists/sloped ceiling) THIS GARAGE HANGING HARDWARE KIT IS OPTIONAL: The Auxx-lift's long side of the platform runs with the ceiling joists. This additional hardware is required when you want the platform to run perpendicular to your joists

Add Remove
$1,459
$2,150 Save $691

or



Auxx-Lift

Order today. Ships:

See after selection is made

Currently out of stock.

Lower the garage storage platform lift at the push of a button. EASY Installation on joists and Rafters - Over 11,000 happy customers
  • No lifting or ladders
  • Steel aircraft cables (Lift tested to UL-standards)
  • Built in the USA - Uses SPAX® PowerLags®
  • Low ceiling hanging height - Competitor's lifts require 4+ ft.
    • INCLUDES: Motors with cables, Platform, Hardware, Remote, struts, step-by-step instructions - For the DIYer or handyman, but we also have installers in all states

0 Reviews

Overall rating No ratings yet

Reviews verfied by Judge.me

5
0
4
0
3
0
2
0
1
0

Write a review

Please enter your name!
Will be displayed on the comment.
Please provide valid email address!
Authentication only - we won't spam you.
Please choose rating!
Please enter a title for your review!
Give your review a title
Please write a review!
Your review must be at least 50 characters.
Drag and drop here to upload

Thank you!

A review has been submitted.
Load more reviews

No reviews yet

Be the first to write a review

Fill out the form
Twitter Pinterest Facebook
Auxx-Lift
Auxx-Lift
$1,459 Out of stock $2,150 Save $691

General specs

  • Model: Auxx-Lift 1400 Auxx-Lift 1600
  • Lifting Capacity: Up to 400 lbs Up to 600 lbs
  • Max. Travel Distance1: 16 ft 22 ft
  • Min. stored height2: 8 in

Roof Support

  • Type: (2) 1 5/8" x 60" strut channel
  • Fasteners: (8) 5/16" x 4" SPAX© Lag Bolts
  • Mounting Area: 5' x 5' over 3 joists/rafters
  • Cable: 1/8” Vinyl-coated Steel 7x19 3/16” Vinyl-coated Steel 7x19
  • Cable Strength3: 2,000 lbs 4,200 lbs

Operating Requirements

  • Switch Voltage: 110V / 120V
  • Transmitter: 433.92 MHz
  • Electrical Cord: 10 FT / 16 gauge / NEMA 5-15
  • Min. circuit size: 15 amp

Platform Specs

  • Thickness: 2.5 inches
  • Support Frame: C-Channels (15gauge)
  • Face material: 3 x 3 galv. Wire Mesh (4gauge)

Motors

  • Type: IP44 (T-Motor)
  • Rated Power: 235 W 680 W
  • Rated Current: 2.2 A 6.0 A
  • Voltage / Phase: 100-120V AC / Single
  • Duty Cycle @ Max. Capacity: 3 min on, 15 min off4

Size and Weight

  • Dimensions: 3ft x 6ft, 3ft x 8ft, 4ft x 6ft, 4ft x 8ft
  • Weight: 128 pounds

Available Finishes

What's in the box

  • 2 Motors
  • Controller
  • Remote Control
  • 2 C-Strut Channels
  • Platform
  • Mounting Hardware

1We offer multiple cable length versions. E.g. The 400 lbs version can be equiped with a cable length to allow 16 ft of travel.

2The distance measured from your ceiling to the bottom of the platform when in raised position.

3Ultimate tensile strength

4If you run the Auxx-Lift continously for more than 3 min at a time, the motors will switch off automatically and require to cool down for 15 min or less.

Auxx-Lift
Auxx-Lift
$1,459 $2,150 Sale
Auxx-Lift in Pearl-White Auxx-Lift in Pearl-White
Gallery thumbnail 3x3 Construction-Grade Galvanized Steel Wire Mesh
Spring-loaded stoppers to protect your floor Spring-loaded stoppers to protect your floor
Platform is made from Heavy Duty C-Channel. Bevelled corner protectors Platform is made from Heavy Duty C-Channel

Most versatile

garage storage solution

Customization to fit your garage storage needs

The Auxx-Lift comes in various sizes, colors, and lifting capacities with one resolute goal: to improve your garage organization.

Platform sizes
3' x 6'
3' x 8'
4' x 8'
4' x 6'
Lifting Capacities
400 lbs.
600 lbs.
Finishes
Silver Gray
Pearl White
Stainless Steel

*Pearl-White and Stainless-Steel finish is not available for all platform sizes.

Popular questions

The Auxx-lift was designed to provide maximum storage, safety, convenience and a strikingly attractive design. We also eliminated the shortcomings of similar storage products such as low-quality components and safety issues. We use C-Channel beams and 1/4" wire mesh (on the platform).

It runs on standard US household power. The motor draws approximately 3.8 Amps. The 12 ft. long power cord can be plugged into the outlets placed in the ceiling for garage door openers or any other outlet.

The mounting frame area on the ceiling that is required is 5

The Auxx-Lift has ceiling mounting struts that are installed across 3 garage ceiling's joists or ceiling supports (The long 8 ft. side is perpendicular to the joists). The storage platform for garages is installed to at least 3 ceilings supports for extra redundancy. If you want the platform lifter installed running with the joists you can purchase an extra hardware kit from our store.

The auxx-lift comes standard for floor-to-ceiling heights of up to 13 ft. We offer longer cables to accommodate up to 20 ft. floor-to-ceiling heights.

The minimum recommended clearance is 18 in between the garage door and the ceiling.

Tools needed

For DIY Installation

Following tools are needed:

  • Wrench set - 13/32", 7/16", 23/32"10mm, 11mm, 18mm
  • Flathead Screw driver 0.04"x0.1" 1x3mm
  • Phillips #1 Screw driver
  • Allen Wrench - 3/16", 3/32"5mm, 2.5mm
  • Level
  • Tape measure
  • Pencil
  • Drill
  • 7/16"11mm socket for drill
  • Drill bit - 1/8", 3/16", 9/32"3mm, 5mm, 7mm
  • Stud finder
  • Line laser
  • Digital Multimeter

Header title displayed

Lorem ipsum dolor sit amet, quia non consectetur adipiscing elit.

Start earning
Become a Courier

Wirelessly controlled

The Auxx-Lift comes with an easy to use wireless remote control allowing you to lower/raise your garage ceiling storage rack from a safe distance.

  • 1
    Auto High & Low Points

    Programmable stopping points allow you to set high and low point parameters, prevent your items hitting the ceiling or floor.

  • 2
    Auto-Stop

    Lift will automatically stop in scenarios where remote control loses connection or runs out of battery.

  • 3
    Active-Press

    Button to move platform needs to be continuously pressed to avoid accidental damage or injury.
